Precision CNC Tungsten Carbide Saw Blade Grinding Sharpening Machine Tfe650

Basic Info

Model NO.	TFE650
Precision	High Precision
Certification	CE, ISO 9001
Condition	New
Item	Saw Blade Sharprning Grinding Machine
Color	White
Weight	1350kg
Power	3kw
Grinding Speed	3~20mm/S
Voltage	380V, 50Hz
Accuracy	0.03mm
Mode	Auto
Certificate	SGS
Loading Port	Tianjin
Transport Package	PE Bag and Wooden Case
Specification	1800 X1350 X1920mm
Trademark	TORSEL
Origin	China
HS Code	8460310000
Production Capacity	1000PCS/Year

Product Description

Precision CNC Tungsten Carbide Circular Saw Blade Grinding Sharpening Machine TFE650

Saw blade diameter	110mm~650mm
Saw blade thickness	0.5~8mm
Side angle	7°~25°
Side relief	5°~-5°
Hook angle	-5°~28°
Bore diameter	12~120mm
Pitch	2~65mm
Tip length	1~15mm
Tip width	1~10mm
Wheel diameter	125mm*32mm*25mm
Wheel speed	5000r/min
Grinding speed	3~20mm/s
Power	3KW
Dimensions	1800*1350*1920mm
Weight	1350kg

1. Mainly used for high-end power tools, general aluminum alloy saw blades, general plate furniture saw blades front and back grinding.2. Three-axis servo + one-axis stepping.3. The chamfer angle and feed amount are all set from the screen, no manual adjustment is required, and the operation is extremely convenient.4. Electronic hand wheel is adopted to set knife, which is very easy to operate.5. The processed specifications can be formulated, the processing parameters can be stored in the memory of the device, and the next processing of this specification can be completed by direct call



1.What is the payment terms?---L/C, T/T2.Which is the grinding surface of the grinding machine TFE650?---It can grind the top and face surface of the tip.3.Where is the loading port?---Tianjin, China.4.Is the company's technology for producing saw blade grinding machines mature?---Sure,our company have more than 120 technicians, and they have more than 20 years working experiences.5.Where is the address of the factory?---Our factory is located in Tangshan city, Hebei province, China.6.What is the grinding accuracy of the grinding machine?---The accuracy of the grinding machine is between 0.01-0.03mm.7. Which tooth surfaces of the saw blade can your grinding machine grind?---It can grind any tooth surface, and you can choose a grinding machine to grind the tooth top, tooth face or side surface according to your needs.8. Are you a manufacturer or a trading company?---We are professional saw blade grinding machine manufacturer. We have more than 120 technicians dedicated to the design, development and production of saw blade grinding machines. And there is an independent sales department and after-sales department to provide you with services.9. How can I select a suitable grinding machine?---You can tell us your requirements of saw blade grinding machine, and other parameters of your saw blades, we will give you professional suggestion.10. Can I contact you if I have any questions?---Sure, we will serve you wholeheartedly, please feel free to contact us if you have any questions.
